Transmitter: Aluminum outer case with plastic bezel
Receiver: Aluminum outer case with plastic bezel
Dimensions:
Receiver: 1.5-in. H x 8.5-in. W x 7.4-in. D (39 x 216 x 187-mm)
Transmitter: 1.5-in. H x 8.5-in. W x 7.4-in. D (39 x 216 x 187-mm)
Weight (Approximate):
Receiver: 2.55 lb. (1.2 kg)
Transmitter: 2.5 lb. (1.1 kg)
Miscellaneous
Additional Information:
General:
Humidity - Transmitter & Receiver: 5 to 95% non-condensing
Encryption - Transmitter: Secure Sockets Layer (SSL) over a TCP/IP up to 128-bit for transmitter to receiver with virtualized targets, depending on configuration;
Receiver: Secure Sockets Layer (SSL) over a TCP/IP up to 128-bit for transmitter to receiver with virtualized targets, depending on configuration
EDID Support - Transmitter: Internal EDID table in transmitter (can be updated from a receiver or manager)
Receiver: Internal EDID table in transmitter (can be updated from a receiver or manager)
Operating Temperature - Transmitter & Receiver: 32° to 104°F (0° to 40° C)
Operating Systems Supported - Transmitter & Receiver: Microsoft Windows Vista, XP, Windows 7, Windows 8, Server 2003, Server 2008, Server 2012, Linux, Solaris, Mac OS
Storage Temperature - Transmitter & Receiver: -4° to 140°F (-20° to 60° C)
Industry Certifications - Transmitter & Receiver: FCC, CE, RoHS
Power - Transmitter: External desktop-style adapter, 100-240 VAC input, 12VD C, 3A connection to unit;
Receiver: External desktop-style adapter, 100-240VAC input, 12VDC, 3A connection to unit
ImportedDistance Supported Imported
Transmitter: Distance between TX and RX:
In IP mode: Unlimited using IP rules;
In DX mode: CATx: 3 2 8 ft. (100 m); Fiber: 9 8 4. 2 ft. to 6 .2 mi. (300 m to 10 km) , based on SFP used;
Receiver: Imported Distance between TX and RX:
In IP mode: Unlimited using IP rules;
In DX mode: CATx: 3 2 8 ft. (100 m); Fiber: 9 8 4. 2 ft. to 6 .2 mi. (300 m to 10 km) , based on SFP used
Operation Imported
Transmitter: Default IP Address: 192.168.1.22; Default Username: admin; Default Password: Blank password by default, just press Enter key; Encryption: Secure Sockets Layer (SSL) over a TCP/I P up to 128-bit for transmitter to receiver with virtualized targets , depending on configuration;
Receiver: Default IP Address: 192.168.1.21; Default Username: admin; Default Password: Blank password by default, just press Enter key; Encryption: Secure Socket s Layer (SSL) over a TCP/I P up to 128-bit for transmitter to receiver with virtualized targets, depending on configuration
Resolution Imported - Transmitter: 4096 x 2160 @ 60 Hz
