Black Box ACU5050A-R2
Limited Warranty

Black Box ACU5050A-R2

Black Box - Black Box ServSwitch Wizard USB KVM Extender With Audio - 1 Computer (s) - 1 Local User (s) - 1 Remote User (s) - 1000 ft. Range - 1900 x 1200 Maximum Video Resolution - 4 x Network (RJ45) - 5 x USB - 2 x VGA - Rack-mountable
  • VGA Video resolution 1600x1200
  • Extended profile DDC EDID ensures optimal video with high-performance display devices
  • Transparent USB 2.0 support
  • Local VGA and stereo audio feedthrough
  • Dual-video monitoring at the CPU
  • Automatic cut-out fuses protect against power surges
  • Rackmount multiple local and remote units in the optional chassis
  • Remote unit includes a built-in 4-port USB hub
Read More
Need a different version? See all Black Box Partss
$1,288.88
+ Add to Quote
Technical Information
Connectivity Technology:
Wired
Number of Computers Supported:
1
Number of Local Users Supported:
1
Number of Remote Users Supported:
1
Maximum Operating Distance:
1000 ft
Video
Maximum Video Resolution:
1900 x 1200
Interfaces/Ports
Network (RJ-45):
Yes
USB:
Yes
Microphone:
Yes
VGA:
Yes
Number of VGA Ports:
2
Number of Network (RJ-45) Ports:
4
Number of USB Ports:
5
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Form Factor:
Rack-mountable
Transmitter Height:
1"
Transmitter Width:
2.90"
Transmitter Depth:
6.40"
Receiver Height:
1"
Receiver Width:
2.90"
Receiver Depth:
6.40"
Transmitter Weight (Approximate):
1 lb
Receiver Weight (Approximate):
1 lb
Miscellaneous
Package Contents:
  • Local Unit
  • Remote Unit
  • USB Cable
  • Audio Cable
  • Video Cable
  • 2 x Rackmounting Plates
  • 8 x self-adhesive rubber feet
  • Power Supply For Remote Unit (PS649-R3)
  • IEC 320 Power Cord
  • Safety Guide
Certifications & Standards:
CE
Environmentally Friendly:
Yes
Environmental Certification:
  • WEEE
  • RoHS
Country of Origin:
United Kingdom
Warranty
Limited Warranty:
2 Year
Item Numbers
GTIN: 0082208806592, 0783555116487, 0818213973871, 0818275178597, 0818279130041, 0822088065937
UPC: 082208806592, 783555116487, 818213973871, 818275178597, 818279130041, 822088065937
EAN: 0082208806592, 0783555116487, 0818213973871, 0818275178597, 0818279130041, 0822088065937
UNSPSC: 43211603
