Bixolon SLP-TX423 – Barcode Label Printer

Part Number: SLP-TX423DE

Model: SLP-TX420

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Recommended Use

Label Print

Print Color Capability

Monochrome

Maximum Mono Print Speed

5 in/s

Maximum Print Resolution (dpi)

300

Product Description:

Barcode Label Printers, Bixolon TX423, Label Printer, RS-232 Serial, Ethernet, USB, White, 5 ips, 300 dpi, Peeler

Explore all Bixolon SLP-TX420 Barcode Label Printers

Add to Quote

Bixolon SLP-TX423DE Barcode Label Printer

Overview

Full specifications (PDF)

Bixolon SLP-TX420 Barcode Label Printer Model Overview

The SLP-TX420 4 inch Thermal Transfer Desktop Label Printer is designed to meet diverse labeling needs in retail, healthcare, warehouse, and parcel storage environments. This compact and durable printer offers an impressive printing speed of up to 7 inches per second while delivering high-quality labels at a resolution of 203 dpi. It's equipped with built-in Bluetooth for mobile device compatibility and supports optional Ethernet and WLAN connectivity. With intelligent functions like Smart Media Detection™ and Intelligent Leap-over™, product labels are efficiently printed, making it an ideal solution for any business that requires precise and reliable labeling solutions.

Key Features

Fast Printing Speed: Up to 7 ips (178 mm/sec).
Compact Design: Suitable for 74 m ribbon.
Mobile Compatibility: Built-in Bluetooth with MFI iAP2 certification.
Smart Features: Auto paper detection and empty label leap-over.
Multiple Media Types: Supports gap, black mark, and continuous labels.
Energy Efficient: Energy Star certified.

Specifications

Printer Method: Thermal Transfer, Direct Thermal
Print Speed: Up to 7 ips (178 mm/sec)
Print Resolution: 203 dpi
Print Width: Up to 108 mm
Media Type: Gap, Black Mark, Notch, Continuous, Fan-Fold
Media Roll Diameter: Up to 130 mm
Weight: 2.35 kg (5.18 lbs.)
Power: External Power Adaptor 100-240V AC, 50/60Hz
Memory: 64MB SDRAM, 128MB Flash ROM
Interface Options: USB + Serial + Parallel; USB + Ethernet + WLAN (optional)
Operating Temperature: 5 to 40°C (41 to 104°F)

Bixolon SLP-TX423DE Barcode Label Printer Overview

Flexible to Use
- Compatible with Android-based smart devices
- Triple interface supported: USB + Serial + Parallel
- Optional Ethernet and WLAN supported (USB dongle type)

Outstanding Form Factor
- Fast printing speed up to 7 ips (178 mm/sec)
- Quick data processing through powerful memory
- Compact design for 74m ribbon
- Energy-efficient product

Intelligent Function
- Smart Media Detection™ is Bixolon's world-class technology that detects label length and media types such as gap media, black mark media, and short length media paper.
- Intelligent Leap-over™ detects empty label and automatically leaps to the next label.
- Compatible with Android-based smart devices

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

5 in/s

Maximum Print Resolution (dpi):

300

Maximum Print Length:

78.74"

Maximum Print Width:

4.16"

Application/Usage:

Desktop

Memory

Standard Memory:

64 MB

Interfaces/Ports

Serial Port:

Yes

USB:

Yes

Network & Communication

Ethernet:

Yes

Wireless LAN:

Yes

Media Types & Handling

Media Type:

Label
Gap
Black Mark
Notch
Continuous Label
Fanfold

Maximum Roll Diameter:

5.12"

Maximum Label Width:

4.33"

Power Description

Power Source:

AC Supply

Physical Characteristics

Height:

6.8"

Width:

7.9"

Depth:

9.9"

Weight (Approximate):

5.18 lb

Miscellaneous

Platform Supported:

Energy Star:

Yes

Environmentally Friendly:

Yes

Country of Origin:

South Korea

Item Numbers

UNSPSC: 43212108
