Axicon 15500 Barcode Verifier
Axicon 15500 -
The Axicon 15500 barcode verifier is designed to read both linear and two dimensional matrix barcodes simultaneously. All the symbols seen in its field of view are verified individually, and the user simply selects each barcode in turn to see the specific results. The field of view - 95mm by 70mm - is the world's largest for a handheld 2D barcode verifier. Linear and 2D barcodes are verified in accordance with the appropriate ISO/IEC standard, with linear barcodes being sampled ten times from top to bottom.
Full specifications (PDF)
Price Match Guarantee
Found a better price? We'll match it within 60 days of your purchase.
for Qty Discount
Add to Quote
Starting at:
$6,495.00
Get help from a Barcoding Expert!
Axicon 15500 Barcode Verifier Options
-
Axicon 15500 Barcode Verifier
Linear and 2D Barcode Verifier, Axicon 15500, 95mm x 70mm field of view, USB powered, Three Different Operating Positions, ISO/IEC compliant.$6,495.00
Axicon 15500 Barcode Verifier Model Overview
The Axicon 15500 Linear and 2D Barcode Verifier is the ideal solution for comprehensive barcode quality analysis. Designed to simultaneously read both linear and 2D matrix barcodes, it effortlessly verifies each symbol in its expansive field of view (95mm x 70mm). Compliance with ISO/IEC standards ensures accurate assessments for a broad range of barcodes, including GS1 DataMatrix and QR Codes. Utilizing USB power, this verifier is user-friendly and connects easily to any Windows-supported PC, making it essential for quality control in various industries.
Key Features
Specifications
Key Features
- Largest field of view (95mm x 70mm) for handheld verifiers
- Three versatile operating positions for easy access to barcodes on all packaging types
- ISO/IEC compliant verification for reliable quality control
- USB powered for convenient connectivity
- Data content checker for multiple barcode types
Specifications
- Dimensions: 205 x 195 x 141 mm (8" x 7.6" x 5.5")
- Weight: 1.5 kg (53 oz)
- Construction: Plastic housing, CMOS sensor, LED illumination
- Power consumption: 360mA from USB host
- Aperture reference numbers: 05, 06, 08, 10, 16, and 20
- Wavelength of light: 660 nm
- Operating temperature: 10° to 40°C
- Storage temperature: -20° to 70°C
- Humidity: 25% to 80% @ 40°C non-condensing
- Warranty: Two years parts and labor - return to bench
