Number of Total Expansion Slots:
6
AudioCodes M1K-MSBG1 Products
Part Number:
M1K-MSBG1
Model:
AudioCodes Parts Accessory Model Overview
Products and parts from AudioCodes.
AudioCodes M1K-MSBG1 Products Overview
Scale Up As Your Business Grows
The Mediant 1000 matches the density requirements for small locations while meeting enterprises and service providers' demands for scalability. The compact Mediant 1000 Modular Gateway is extremely scalable and supports multiples of 1, 2, or 4 E1/T1/J1 spans, 4 to 20 BRI ports or 1 to 24 analog ports in various FXO/FXS configurations. The Mediant 1000 also supports mixed digital/analog with media processing capabilities such as conferencing, play/record configurations.
The Mediant 1000 can support a variety of telephony interfaces. The digital module can be configured as regular E1/T1/J1 interfaces, with up to 1 or 2 paired spans acting as life-line interfaces for switching to the PSTN in case of power failure or network problems. The analog module is available as regular FXS or FXO interfaces, where 1 FXS line can be used as a life-line interface for switching to the PSTN.
I/O Expansions
Management & Protocols
Voice Codec:
- T.38
- G.711
- G.165
- G.168
- G.723.1
- G.726
- G.727
- G.729
- GSM
- iLBC
Physical Characteristics
Form Factor:
- Rack-mountable
- Desktop
Compatible Rack Unit:
1U
Miscellaneous
Additional Information:
Built-in Open Solution Network (OSN) server option (based on an Intel processor).
Item Numbers
UNSPSC:
43222605
Get help from a Barcoding Expert!
The AudioCodes M1K-MSBG1 Products is also known as
AUC-M1KMSBG1
