KVM Switch:
Yes
Number of Computers Supported:
8
ATEN CL6708MW Ethernet Switch
Part Number:
CL6708MW
Model:
Parts
ATEN Parts Wireless Switch Model Overview
Parts and accessories from ATEN.
ATEN CL6708MW Ethernet Switch Overview
The CL6708MW brings additional versatility to ATEN's line of LCD KVM Switches with its native DVI compatibility. Building on ATEN's renowned, space-saving approach to KVM switches - which integrates an LCD panel, full keyboard, and touchpad into a streamlined, 1U housing - the CL6708MW is a highly-scalable LCD KVM switch which features the ability to control up to 64 computers by cascading 8 additional CS1768 8-port KVM switches.
Featuring an integrated 17.3" LED-backlit LCD panel capable of full HD 1080p video - greater clarity than typical analog interfaces - the CL6708MW incorporates the YUV video format for greater compatibility with high-definition signals (e.g. NVR sources). Similarly, the CL6708MW is High-Bandwidth Digital Content Protection (HDCP) compatible, making it well-suited for use with content-protected media in corporate, educational, and commercial settings.
To further enhance usability, ATEN's LED illumination light is included to ensure keyboard and touchpad visibility in low-light conditions.
Technical Information
Display & Graphics
Screen Size:
17.3"
Display Screen Type:
LED
Screen Mode:
Full HD
Screen Resolution:
1920 x 1080
Input Devices
Keyboard:
Yes
Pointing Device Type:
TouchPad
Interfaces/Ports
USB:
Yes
DVI:
Yes
Number of USB Ports:
11
Number of DVI Ports:
9
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Input Voltage Range:
100V AC to 240V AC
Power Consumption:
29.26 W
Physical Characteristics
Product Material:
- Metal
- Plastic
Rack Height:
1U
Height:
1.7"
Width:
18.9"
Depth:
27.1"
Weight (Approximate):
28 lb
Miscellaneous
Package Contents:
- CL6708MW Single Rail 8-Port DVI FHD LCD KVM Switch with Standard Rack Mount Kit
- 2 x KVM Cable (DVI-D, USB, Audio; 1.8m/6ft)
- 1 x Power Cord
- 1 x Firmware Upgrade Cable
- 1 x User Instructions
Platform Supported:
- PC
- Linux
- Sun
Environmentally Friendly:
Yes
Country of Origin:
Taiwan
Item Numbers
GTIN:
0672792006845
UPC:
672792006845
EAN:
0672792006845
UNSPSC:
43222634
