HPE Aruba 560 Series Wireless Access Points Model Overview
Ideal for campuses, venues and industrial sites, the 560 Series AP offers enterprise-class Wi-Fi 6 in a rugged outdoor form factor. Two 2×2:2 radios deliver up to 1.49 Gbps aggregate throughput with OFDMA and MU-MIMO for efficient multi-user access. Its IP55-rated enclosure resists dust, moisture and extreme temperatures, while integrated Bluetooth 5 and Zigbee radios support IoT deployments. Automated provisioning and centralized management reduce operational complexity, and policy enforcement firewalls keep guest and operational traffic secure.
Key Features
1.49 Gbps aggregate Wi-Fi 6 performance
OFDMA and MU-MIMO for optimized capacity
IP55-rated, –40 °C to +65 °C; weather and wind resistant
Bluetooth 5 & Zigbee for seamless IoT integration
Zero-touch provisioning and cloud management
Dynamic segmentation and built-in firewall
Specifications
5 GHz HE80: 1.2 Gbps; 2.4 GHz HE40: 574 Mbps
Model options: internal omni or integrated directional antenna
1×1 GbE RJ-45 port for uplink
Power options: 802.3af/at PoE or 12 V DC
Power consumption: 15.6 W max; 4.2 W idle
Size: 110 × 165 × 165 mm; Weight: 1.09 kg
HPE Aruba R4W50A Wireless Access Points Overview
Entry-level Wi-Fi 6 (802.11ax) for outdoor and warehouse environments
Weatherproof and temperature hardened, Aruba 560 series access points deliver cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging locations.
Purpose-built to survive in the harshest outdoor environments, 560 series can withstand exposure to extreme high and low temperatures, persistent moisture and precipitation, and are fully sealed to keep out airborne contaminants. All electrical interfaces include industrial strength surge protection.
Aruba Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing numbers of IoT and mobility requirements. With maximum aggregate on air data rate of 1.49 Gbps (HE80/HE20), they deliver the speed and reliability needed for most environments.
The Aruba advanced ClientMatch technology and an integrated Bluetooth beacon can help enable Aruba location services.
What Wi-Fi 6 performance can I expect from the HPE Aruba 560 Series AP?
The HPE Aruba 560 Series delivers up to 1.49 Gbps aggregate throughput across its dual 2×2:2 radios, with 1.2 Gbps on the 5 GHz band (HE80) and 574 Mbps on the 2.4 GHz band (HE40). OFDMA and MU-MIMO technologies optimize capacity for efficient multi-user access in high-density environments like campuses and venues. We offer this access point as an ideal solution for enterprises requiring enterprise-class Wi-Fi 6 performance in outdoor deployments.
Is the HPE Aruba 560 Series suitable for outdoor and harsh environments?
Yes, the 560 Series is specifically engineered for outdoor deployment with an IP55-rated enclosure that resists dust and moisture. It operates reliably across extreme temperature ranges from –40 °C to +65 °C and is designed to withstand challenging weather and wind conditions. This rugged construction makes it ideal for campuses, industrial sites, and outdoor venues where standard indoor access points would fail.
What IoT connectivity options does this access point provide?
The HPE Aruba 560 Series integrates Bluetooth 5 and Zigbee radios alongside Wi-Fi 6, enabling seamless IoT device integration without requiring separate hardware. These built-in radios allow you to connect and manage IoT sensors, beacons, and smart devices directly through the access point. This unified approach simplifies deployment and reduces infrastructure complexity across your wireless network.
How is the HPE Aruba 560 Series powered, and what are its power requirements?
The access point supports flexible power options: standard 802.3af/at Power over Ethernet (PoE) or direct 12 V DC connection, giving you deployment flexibility based on your infrastructure. Maximum power consumption is just 15.6 W under full load, with only 4.2 W during idle operation, making it energy-efficient for large-scale outdoor deployments. Visit barcodesinc.com to discuss power infrastructure requirements for your specific deployment scenario.
What management and provisioning capabilities does the 560 Series offer?
The HPE Aruba 560 Series features zero-touch provisioning and cloud-based centralized management, significantly reducing operational complexity during large deployments. Built-in dynamic segmentation and firewall capabilities enforce security policies between guest and operational traffic without requiring external appliances. These enterprise-grade management features ensure consistent security and performance across your wireless infrastructure.
What antenna options are available for the HPE Aruba 560 Series?
We offer the 560 Series in two antenna configurations: integrated omnidirectional antenna for 360-degree coverage in open areas, or integrated directional antenna for focused coverage in specific directions. The model designation indicates which antenna type is included, allowing you to choose the best option for your site topology and coverage requirements. Contact us today to determine which antenna configuration best suits your deployment needs.
