HPE Aruba 7200 Series Wireless Controllers Model Overview
The Aruba 7200 series Mobility Controller is the next-generation networking platform, optimized for mobile application delivery to ensure the best mobility experience over Wi-Fi. With a new central processor that employs up to eight cores with four threads each, its like having a total of 32 virtual CPUs. As a result, the 7200 series supports up to 32,000 mobile devices and performs stateful firewall policy enforcement at 40 Gbps ?? plenty of capacity and speed for BYOD and 802.11ac devices.New levels of visibility are provided by Arubas unique AppRF technology, which runs on 7200 series Mobility Controllers. With AppRF, IT can see applications by user, including top web-based applications like Facebook and Box.
HPE Aruba JW650A Wireless Controllers Overview
The Aruba 7200 series Mobility Controller is the next-generation networking platform, optimized for mobile application delivery to ensure the best mobility experience over Wi-Fi.
With a new central processor that employs eight cores with four threads each, it's like having a total of 32 virtual CPUs. As a result, the 7200 series supports 32,000 mobile devices and performs stateful firewall policy enforcement at 40 Gbps - plenty of capacity and speed for BYOD and 802.11ac devices.
New levels of visibility are provided by Aruba's unique AppRF technology, which runs on 7200 series Mobility Controllers. With AppRF, IT can see applications by user, including top web-based applications like Facebook and Box.
The 7200 series also manages authentication, encryption, VPN connections, IPv4 and IPv6 Layer 3 services, the Aruba Policy Enforcement Firewall, Aruba Adaptive Radio Management, and Aruba RFProtect spectrum analysis and wireless intrusion protection.
Clustering and centralized management enable the deployment of large networks with hundreds of Mobility Controllers with minimal staff. A master Mobility Controller can manage local Mobility Controllers, while Aruba AirWave network management provides enterprise-wide clarity and control through real-time monitoring, historical reporting and troubleshooting.
Architected for high AvAilAbility
Redundant power supplies: The 7200 series supports dual, field-replaceable redundant power supplies to maintain uninterrupted network operations.
Hot-swappable fan tray with multiple fans: The 7200 series includes a field-replaceable fan tray with multiple fans, providing sufficient cooling and rapid time to repair.
Solid state drives for maximum reliability and uptime.
Two dual-media ports: 1000BASE-X or 10/100/1000BASE-T connections for high availability.
What are the network connectivity specifications of the HPE Aruba JW650A?
The HPE Aruba JW650A Wireless Controller features 4x 10GBase-x (SFP/SFP+) ports and 2x dual media ports that support both 10/100/1000BASE-T or SFP connectivity. This high-speed connectivity architecture is designed to handle enterprise-scale wireless deployments with multiple access points and thousands of mobile devices. We offer the JW650A with a single 350W DC power supply (-48V DC) configured for US regulatory domains.
How many mobile devices can the Aruba 7200 series controller support?
The Aruba 7200 series Mobility Controller, including the JW650A model, supports up to 32,000 mobile devices simultaneously. With its advanced multi-core processor featuring up to eight cores with four threads each (equivalent to 32 virtual CPUs), the controller delivers the processing power necessary for large BYOD deployments and 802.11ac wireless networks. This capacity makes it ideal for enterprise environments requiring robust mobility management.
What firewall performance does the Aruba JW650A provide?
The Aruba JW650A performs stateful firewall policy enforcement at 40 Gbps, providing enterprise-grade security without compromising network throughput. This high-performance firewall capacity ensures that security policies can be applied across thousands of connected devices without creating bottlenecks. Contact us today to discuss how this firewall performance meets your organization's security requirements.
What visibility and application management features does the JW650A offer?
The Aruba JW650A includes AppRF technology, which provides unique visibility into applications by user and can identify top web-based applications like Facebook and Box. This application-level intelligence enables IT teams to monitor, manage, and optimize application delivery across the wireless network. AppRF helps organizations enforce usage policies and prioritize business-critical applications in their mobile environments.
Is the HPE Aruba JW650A suitable for BYOD environments?
Yes, the Aruba JW650A is specifically designed for BYOD (Bring Your Own Device) deployments, with capacity to support up to 32,000 mobile devices and performance optimized for 802.11ac wireless networks. The controller's 40 Gbps stateful firewall enforcement and AppRF application visibility provide the security and management controls necessary for diverse device types and user-owned equipment. Visit barcodesinc.com to explore how we can support your BYOD wireless infrastructure.
What power specifications should I plan for when deploying the JW650A?
The Aruba JW650A includes one 350W DC power supply operating at -48V DC, making it suitable for data center and telecom-style power infrastructure. The controller is designed for high-availability deployments where redundant power supplies can be configured for fault tolerance. Contact us today for guidance on power architecture and redundancy options for your specific deployment scenario.
The HPE Aruba JW650A Wireless Controllers is also known as
HPE-JW650A
Full specifications (PDF)
