Aruba JW297A Access Point

The Aruba JW297A Access Point has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Aruba RAP-3 - Remote Access Point (wireless, 3x10/100Base-T, USB, POE out) - Restricted regulatory domain: United States
  • Create a wireless network and share your Internet connection and files with other devices while checking emails
  • Featuring Fast Ethernet port to speed up the transfer rate up to 100Mb/sec to connect your wired network
  • Uses ISM Band to connect your computers, wireless printers, game consoles, and other Wi-Fi devices for a smooth network experience
  • For USB-enabled devices accessibility, the router comes with a built-in USB port
  • Can be placed on the desktop surface for standalone installation
Read More
Discontinued Need Assistance?
Recommended TrueSupport Coverage (/mo.)

x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device

Only /month
Subtotal ( items)

x
You've just added this product to the cart:

Go To Cart
Add to Quote
Aruba RAP-3 Accessory Model Overview
The Aruba RAP-3 extends corporate resources to remote locations by establishing site-to-site VPN tunnels to the data center. The RAP-3 delivers a wireless data rate of up to 300 Mbps, and has three 10/100BASE-T Ethernet ports and one USB port for connecting to 3G and 4G networks. It is also available with an 802.3af power-over-Ethernet (PoE) port for IP phones or other devices.
Aruba JW297A Access Point Overview
The multifunctional Aruba RAP-3 delivers secure 802.11n wireless and wired network access to corporate resources from branch and home offices.

Centrally managed by Aruba Mobility Controllers, the RAP-3 extends corporate resources to remote locations by establishing site-to-site VPN tunnels to the data center. To eliminate client stickiness, the RAP-3 includes integrated ClientMatch technology, which continuously gathers session performance metrics and uses this data to every device to the best AP and radio on the WLAN, even while users roam and RF conditions change.

The RAP-3 also offers a variety of enterprise-class features, including role-based network access, policy-based forwarding, and Adaptive Radio Management (ARM), which gives remote workers the same high-quality Wi-Fi experience they get at corporate headquarters.

Delivering a wireless data rate of up to 300 Mbps, the RAP-3 has three 10/100BASE-T Ethernet ports and one USB port for connecting to 3G and 4G networks. It is also available with an 802.3af power-over-Ethernet (PoE) port (RAP-3WNP model) for IP phones or other devices.

At locations that require greater coverage, the RAP-3 can join an Aruba Instant WLAN cluster. Simply install additional RAP-3s or any Instant AP and the entire cluster is managed as one. If one Instant AP fails, another AP automatically takes over with no disruption.

For large installations across multiple sites, the Aruba Activate service significantly reduces deployment time by automating device provisioning, firmware upgrades, and inventory management. With Aruba Activate, Instant APs are factory-shipped to any site and configure themselves when powered up.
Technical Information
Wi-Fi Generation:
Wi-Fi 4
Wireless Specifications
Broadband Transmission Technology:
Ethernet
Wireless LAN Standard:
IEEE 802.11n
ISM Band:
Yes
UNII Band:
No
ISM Maximum Frequency:
2.40 GHz
Cellular Generation:
4G
Total Number of Antennas:
2
Number of Internal Antennas:
2
Total Wireless Transmission Speed:
37.50 MB/s
Interfaces/Ports
Number of Network (RJ-45) Ports:
2
USB:
Yes
PoE (RJ-45) Port:
No
Number of Broadband (RJ-45) Ports:
1
Network & Communication
Ethernet Technology:
Fast Ethernet
VPN Supported:
No
Physical Characteristics
Form Factor:
  • Desktop
  • Wall Mountable
Height:
4.3"
Width:
5.1"
Depth:
2.5"
Weight (Approximate):
6.60 oz
Miscellaneous
Certifications & Standards:
  • cTUVus
  • Environmentally Friendly:
    Yes
    Warranty
    Limited Warranty:
    Lifetime
    Item Numbers
    GTIN: 0190017169026
    UPC: 190017169026
    EAN: 0190017169026
    UNSPSC: 43222609
    Get help from a Barcoding Expert!

    What type of Barcode are you scanning?

    The Aruba JW297A Access Point is also known as HPE-JW297A
