HPE Aruba JL070A#ABA Ethernet Switch

Part Number: JL070A#ABA
Model: Parts
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$939.49

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Network Ports
8
Token Ring Port
No
LRE Port
No
Uplink Port
No

Product Description:

  Aruba 2530 8 PoE+ Internal PS Swch U.S. - English localization
Explore all HPE Aruba Parts Accessories
Add to Quote
HPE Aruba JL070A#ABA Ethernet Switch
HPE Aruba JL070A#ABA Ethernet Switch
HPE Aruba JL070A#ABA Ethernet Switch HPE Aruba JL070A#ABA Ethernet Switch

HPE Aruba Parts Accessory Model Overview

Products and parts from Aruba.
HPE Aruba JL070A#ABA Ethernet Switch Overview
The HP 2530 Switches Series provides security, reliability, and ease of use for enterprise edge, branch office, and SMB deployments. Fully managed switches deliver full Layer 2 capabilities with optional PoE+, 10GbE uplinks, enhanced access security, traffic prioritization, sFlow, IPv6 host support, and include Limited Lifetime Warranty 2.0 with 3 years 24x7 phone support.

The HP 2530 Switch Series is easy to use and deploy, and can be manages with the HP Intelligent Management Center (IMC) for a single view of your entire network.
Interfaces/Ports
Total Number of Network Ports:
8
Token Ring Port:
No
LRE Port:
No
Uplink Port:
No
Bypass:
No
Modular:
No
Management Port:
Yes
USB:
Yes
Number of PoE+ (RJ-45) Ports:
8
Stack Port:
No
Number of Network (RJ-45) Ports:
2
Port/Expansion Slot Details:
  • 8 x Fast Ethernet Network
  • 2 x Gigabit Ethernet Network
  • 2 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
  • Twisted Pair
  • Optical Fiber
Ethernet Technology:
  • Fast Ethernet
  • Gigabit Ethernet
Network Technology:
  • 10/100Base-TX
  • 1000Base-T
  • 1000Base-X
I/O Expansions
Number of Total Expansion Slots:
2
Expansion Slot Type:
SFP
Shared SFP Slot:
Yes
Number of SFP Slots:
2
Network & Communication
Layer Supported:
2
Management & Protocols
Manageable:
Yes
Management:
  • IMC - Intelligent management center
  • Command-line interface
  • Web browser
  • Configuration menu
  • Out-of-band management (serial RS-232c or micro usb)
  • IEEE 802.3 ethernet MIB
  • Repeater MIB
  • Ethernet interface MIB
Memory
Standard Memory:
256 MB
Memory Technology:
DDR3 SDRAM
Flash Memory:
128 MB
Power Description
PoE (RJ-45) Port:
No
Power Source:
Power Supply
Redundant Power Supply Supported:
No
Physical Characteristics
Form Factor:
  • Desktop
  • Wall Mountable
  • Rack-mountable
Height:
1.8"
Width:
10"
Depth:
6.3"
Weight (Approximate):
2 lb
Miscellaneous
Certifications & Standards:
Safety:
  • UL 60950-1
  • CAN/CSA 22.2 No. 60950-1
  • EN 60825
  • IEC 60950-1
  • EN 6095
Emissions:
  • FCC Class A
  • EN 55022/CISPR-22 Class A
  • VCCI Class A
Immunity:
  • EN 55024, CISPR 24
  • EN 55024, CISPR 24
  • IEC 61000-4-2
  • IEC 61000-4-3
  • IEC 61000-4-4
  • IEC 61000-4-5
  • IEC 61000-4-6
  • IEC 61000-4-8
  • IEC 61000-4-11
  • EN 61000-3-2, IEC 61000-3-2
  • EN 61000-3-3, IEC 61000-3
IEEE Standards:
  • 802.3
  • 802.3u
  • 802.3at
  • 802.3ab
Environmentally Friendly:
Yes
Environmental Certification:
  • REACH
  • RoHS
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN: 0657379383250
UPC: 657379383250
EAN: 0657379383250
UNSPSC: 43222612
