HPE Aruba AP-ANT-90 Wireless Antenna

Part Number: AP-ANT-90
Model: Antennas
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Directivity
Omni-directional
Frequency Band Type
UHFSHF
Operating Frequency Range
2.4 GHz to 2.5 GHz4.9 GHz to 5.99 GHz
Antenna Gain
3.3 dBi

Product Description:

  Aruba Networks AP-ANT-90 Omni-Directional Diversity Antenna - 2.83 dBi, 3.31 dBi - N-type
Explore all HPE Aruba Antennas Accessories
Add to Quote
HPE Aruba AP-ANT-90 Wireless Antenna
HPE Aruba AP-ANT-90 Wireless Antenna
HPE Aruba AP-ANT-90 Wireless Antenna HPE Aruba AP-ANT-90 Wireless Antenna

HPE Aruba Antennas Accessory Model Overview

Aruba antenna options.
HPE Aruba AP-ANT-90 Wireless Antenna Overview

The Aruba AP-ANT-90 is a dual-band, spatial diversity, high-performance outdoor down-tilt omni antenna designed for serving WLAN services to clients across multiple bands or where spatial diversity is desired in a single antenna package. It suits a variety of applications including comprehensive outdoor area coverage from various high mount locations such as lighting gantries, derricks or warehouse ceilings. AP-ANT-90 supports spectral coverage from 2.4-2.5GHz & 4.9-5.99GHz frequencies from each antenna interface of which the device supports two. It's housing is UV stabalized and weather proof for care free outdoor deployment, mountable on any overhead area, gantry or pole.

Technical Information
Directivity:
Omni-directional
Frequency Band Type:
  • UHF
  • SHF
Operating Frequency Range:
  • 2.4 GHz to 2.5 GHz
  • 4.9 GHz to 5.99 GHz
Antenna Gain:
3.3 dBi
Impedance:
50 Ohm
Polarization:
Linear Vertical
Interfaces/Ports
Connector Type:
N-Type
Physical Characteristics
Height:
3.66"
Width:
0.89"
Depth:
6.16"
Miscellaneous
Application/Usage:
Wireless Data Network
Additional Information:
  • VSWR: < 2.0:1
  • Housing: Acrylic/PVC and Weatherproof
  • FLY Cable Length: Dual 36 inch

Beamwidth:

  • Elevation:
  • Lowband 2.400-2.500Ghz (57 to 61 degree)
  • Highband 4.900Ghz (61 degree)
  • Highband 5.150Ghz (59 degree)
  • Highband 5.550Ghz (57 degree)
  • Highband 5.900Ghz (55 degree)
  • Azimuth:
  • Omni-directional (360 degree)
Item Numbers
UNSPSC: 43221706
