The Cisco N5K-C5648Q is a 2RU chassis with 24 40-gigabit ports designed for high-performance data center networking. It supports advanced Layer 2 and Layer 3 features including VXLAN, EtherChannel technology (up to 24 ports per group), 64-way Equal-Cost Multipath (ECMP) routing, and comprehensive security with up to 4096 ACL entries. We offer this switch for organizations requiring dense, high-speed connectivity in virtualized environments.
Yes, the N5K-C5648Q fully supports advanced VLAN management and spanning tree functionality, including Rapid Per-VLAN Spanning Tree Plus (PVRST+), MSTP with up to 64 instances, Spanning Tree PortFast, Root Guard, and Bridge Assurance. These features ensure network redundancy and loop prevention across your infrastructure. Contact us today to discuss VLAN configuration options for your deployment.
The N5K-C5648Q supports a comprehensive set of Layer 3 routing protocols including Static routing, RIPv2, EIGRP, OSPF, IS-IS, and BGP, along with HSRP and VRRP for high availability. It also provides VRF-Lite (IP VPN) capability with VRF-aware unicast and multicast support, making it suitable for complex multi-tenant and service provider environments. Visit barcodesinc.com to learn more about our networking solutions.
The N5K-C5648Q supports jumbo frames up to 9216 bytes on all ports, enabling efficient transmission of large data packets across your network infrastructure. This capability improves throughput for bandwidth-intensive applications and reduces overhead in high-performance computing environments.
The switch provides multiple layers of security including Ingress ACLs (standard and extended), VLAN-based ACLs (VACLs), Port-based ACLs (PACLs), ACLs on virtual terminals (VTYs), and routed ACLs with Layer 3 and 4 matching capabilities for both IPv4 and IPv6 traffic. These features allow granular control over network access and traffic filtering. We offer comprehensive support to help configure security policies tailored to your organization's requirements.
Yes, the N5K-C5648Q provides multiple management interfaces including XML, scriptable command-line interface (CLI), and Cisco DCNM (Data Center Network Manager) web services for centralized management and orchestration. This enables seamless integration with your existing data center management infrastructure and automation workflows. Contact us today to discuss management integration options for your network.
Full specifications (PDF)
