APG JB182-BL1816-C Cash Drawer

The Impinj R700 has a ruggedized, shock-resistant die-cast aluminum enclosure weighing 2.12 lb. (0.96 kg), rated to United States Military Standard MIL-STD-810G for shock and vibration. Its operating temperature range is -4° F to 122° F (-20° C to 50° C) at 5–95% non-condensing humidity.

Note the sealing rating is IP50 — protected against dust, but with no rating for water ingress. The reader itself should be installed indoors or in a protected enclosure, even though Impinj offers outdoor-rated antennas such as the Times-7 Slim Outdoor and Compact Outdoor models for the read zone itself. Mounting is via VESA 100 x 100 on the enclosure bottom or two removable brackets compatible with the Impinj Speedway mounting system. Under FCC rules, professional installation is required.

The Impinj R700 runs a secure, field-upgradable Linux operating system on a 5.1 kernel. It uses an encrypted software image and a secure software boot with chain-of-trust, which prevents unauthorized software from executing on the reader — a common requirement in enterprise and retail deployments where readers sit on the corporate network.

It supports 802.1x port security for network access control, HTTPS and SSH for encrypted management, and event logs with syslog forwarding for centralized monitoring. Firmware upgrades are web-based and can be performed remotely, so a distributed fleet can be patched without site visits.

The Impinj R700 supports four development paths. A RESTful interface allows host-based applications in over 80 languages, connecting the reader to IoT applications the same way as other IoT devices. The Octane SDK covers host-based .NET and Java development, and the LLRP Toolkit covers .NET, Java, C and C++.

For on-reader applications, the Embedded Toolkit supports C and C++ running in a 128 MB custom application partition, so tag-processing algorithms can execute at the edge rather than sending raw reads upstream. Gigabit Ethernet keeps latency low and prevents data bottlenecks. Firmware is Impinj R700 LLRP with Impinj extensions, and the network stack supports IPv4 and IPv6 with SSH, HTTP, HTTPS, NTP, DHCP, SFTP and mDNS services.

The Impinj R700 is powered exclusively over Ethernet — either PoE (802.3af) or PoE+ (802.3at) — with no separate DC input. Where the reader is not connected to a PoE-capable switch, an Impinj midspan power injector (part IPJ-A2010) adds inline power to the network connection.

The power source does affect RF performance. On PoE, maximum transmit power is 30 dBm; on PoE+, it rises to 33 dBm. When connected to a device supporting Link Layer Discovery Protocol (LLDP), the R700 checks whether PoE+ is available and configures itself to use it automatically. If maximum read range matters, verify the switch or injector delivers PoE+.

The R700 is a substantial hardware generation ahead. Its receive sensitivity is -92 dBm versus -84 dBm on the Speedway R420 — an 8 dB improvement that lets it read smaller tags and reach further. Processing moves from a 400 MHz single-core to a 1 GHz dual-core processor, RAM from 256 MB to 1,024 MB, and the custom application partition from 32 MB to 128 MB.

Connectivity improves as well: Gigabit Ethernet replaces 10/100, USB peripheral slots go from one to three, and the GPIO block is integrated rather than sold as an accessory. Both readers have four antenna ports, 32 maximum read zones and an 1,100 reads-per-second rate, and both support PoE and PoE+. Maximum transmit power rises slightly, from 32.5 dBm to 33.0 dBm.

The Impinj R700 is a four-port fixed RAIN RFID reader built for enterprise-grade deployments. It complies with the GS1 UHF Gen2v2 air interface standard, standardized by ISO/IEC as 18000-63, and reads up to 1,100 tags per second with a maximum receive sensitivity of -92 dBm at a 10⁻³ bit error rate.

Unlike a handheld reader, the R700 is mounted in a fixed position and connected to external antennas — four monostatic RP-TNC ports supporting up to 32 read zones. It ships in two regional variants: IPJ-R700-141 for FCC markets and IPJ-R700-241 for ETSI markets. Typical applications include loss prevention, pallet tracking, real-time inventory management, asset management, conveyor systems and supply chain visibility.

The Linea Pro Rugged is designed to work with iPod touch 5th, 6th, and 7th generation devices. This compatibility ensures you can deploy reliable scanning across multiple iPod generations in your warehouse or logistics operation. We offer this scanner as a complete solution for iPod-based mobile workflows.

The Epson TM-L90II is a compact thermal label printer designed for high-speed printing of labels and receipts in retail and logistics environments. It offers print speeds up to 150mm per second, supports multiple label widths from 8mm to 112mm, and features both USB and Ethernet connectivity options. The printer's compact footprint makes it ideal for space-constrained warehouse and retail locations where efficiency is critical.

The Honeywell Xenon Ultra 1960g delivers advanced 1D and 2D barcode scanning, including PDF417 support, with a green-dot LED and white illumination aids for enhanced targeting accuracy. Its HD focus technology excels at reading high-density and low-quality codes, making it ideal for challenging warehouse and logistics environments. We offer this model as a complete USB kit ready for immediate deployment in your operations.

The Honeywell Xenon Ultra 1960h features an anti-microbial housing with silver-ion additives that discourages the growth of germs and bacteria, making it ideal for clinical settings. Its improved design with fewer nooks and crannies reduces areas where pathogens can linger, and the housing is resilient to multiple cleanings and disinfection protocols. We offer this scanner specifically designed to help healthcare organizations maintain safe, sanitary equipment while supporting fast and accurate patient care delivery.

Yes, the Linea Pro Rugged is specifically engineered for harsh industrial conditions with enhanced drop protection, 100% dust-tight sealing, and protection against projected water. These rugged specifications make it ideal for demanding warehouse, logistics, and field operations where equipment durability is critical. Available from us for immediate deployment.

Yes, the Honeywell Xenon Ultra 1960g is available in optional dual-camera extended range (XR) models that enable both up-close and extended range scanning capabilities. This flexibility allows your team to scan codes at varying distances without repositioning, improving workflow efficiency in diverse warehouse settings. Contact us today to discuss which configuration best fits your scanning requirements.

Yes, the Honeywell 1960HHD-5USB-N is a 2D imager scanner that reads both 1D and 2D barcodes, including PDF417 and QR codes. This multi-format capability makes it versatile for healthcare applications requiring patient identification, medication verification, and specimen tracking. Contact us today to confirm specific barcode format requirements for your facility.

Yes, the TM-L90II is compatible with major barcode and label design software platforms, and we offer integration support for warehouse management systems and point-of-sale applications. The printer supports standard thermal label formats and ESC/POS command language, ensuring seamless integration with most existing enterprise systems. Contact us today for specific compatibility verification with your current infrastructure.

The Honeywell 1960HHD-5USB-N connects via USB Type A with a 3M straight cable, providing reliable wired connectivity to point-of-care systems and EMR platforms. The USB connection ensures consistent power delivery and data transmission without the latency concerns of wireless alternatives. Available from us with standard NA/MX configuration.

The Linea Pro Rugged features a hot-swappable battery design that allows you to replace the battery without powering down the device or interrupting operations. This capability is essential for 24/7 warehouse and logistics workflows where continuous scanning availability is required. Contact us today to learn more about supporting round-the-clock operations.

The TM-L90II offers multiple connectivity options including USB and Ethernet, allowing flexible deployment in networked warehouse and retail environments. This dual connectivity ensures you can integrate the printer into your existing infrastructure whether you prefer direct device connection or network-based printing. We can help you select the right configuration for your operational needs.

This model features a USB Type A connection with a 3M straight cable, providing reliable plug-and-play integration with your existing systems. The wired USB connection ensures consistent power delivery and data transmission without the complexity of wireless pairing or battery management. We stock this configuration for immediate availability to support your operational needs.

The Epson TM-L90II is designed to operate reliably in standard warehouse and retail environments with operating temperatures ranging from 0°C to 40°C and humidity levels between 10% and 80% non-condensing. The printer's durable thermal print head and robust construction make it suitable for high-volume daily use in demanding logistics and distribution settings. For specific environmental requirements in your facility, visit barcodesinc.com or contact our team for detailed specifications.

Absolutely—the Xenon Ultra 1960g is engineered as a premium general-purpose scanner that integrates seamlessly into high-volume warehouse and logistics workflows. Its advanced scanning technology, combined with improved ergonomic design and accurate targeting aids, makes it well-suited for demanding distribution center environments. Visit barcodesinc.com or contact us today to learn how this scanner can enhance your operation's throughput.

The Honeywell Xenon Ultra 1960h represents the next generation of Xenon scanner technology, building on the legacy of the Xenon and Xenon XP healthcare scanners with improved scanning capability and an enhanced design. It incorporates anti-microbial silver-ion additives and a streamlined form factor with fewer crevices, addressing durability and hygiene concerns that healthcare organizations identified in previous models. Our team can help you understand the specific performance improvements for your clinical workflows.

The Linea Pro Rugged delivers fast and reliable barcode scanning performance optimized for iPod touch devices in industrial settings. The combination of rugged design and responsive scanning makes it suitable for high-volume warehouse and logistics applications. Visit barcodesinc.com for detailed performance specifications and technical documentation.

The TM-L90II delivers improved print speed and reliability compared to earlier thermal printer generations, with faster throughput ideal for high-volume warehouse operations. It maintains the compact design warehouse managers expect while offering enhanced connectivity and broader media compatibility for modern supply chain applications. We offer both current and legacy thermal printer models—contact us today to discuss which solution best fits your operational requirements.

The Xenon Ultra 1960g represents Honeywell's next generation of scanning capability with updated modern design, enhanced green-dot LED targeting, white illumination aids, and improved accuracy on challenging codes. The newer architecture delivers superior performance on high-density and low-quality barcodes compared to earlier models. We can help you evaluate the performance gains for your specific application—contact us today for a detailed comparison.

Yes, the Honeywell 1960HHD-5USB-N is disinfectant-ready with an anti-microbial housing that is resilient to multiple cleanings and chemical disinfection protocols commonly used in healthcare settings. The silver-ion additives in the housing actively discourage microbial growth between cleanings. Visit barcodesinc.com to learn more about our disinfectant-ready scanner options for infection control compliance.

The scanner features 100% dust-tight construction and protection against projected water, making it suitable for damp warehouse conditions and outdoor logistics operations. This environmental protection ensures consistent scanning performance even in challenging weather or wet facility conditions. We offer this solution for operations requiring reliable performance in moisture-prone environments.

The Honeywell 1960HHD-5USB-N includes vibration feedback to confirm successful barcode reads, helping clinicians know that patient or medication data has been captured without requiring visual or audible confirmation in busy clinical environments. This tactile feedback improves workflow efficiency and reduces the need for additional verification steps. Contact us today for detailed specifications on all feedback modes available.

The 1960GHD is built as a general-purpose scanner with black housing designed for standard warehouse, logistics, and retail environments. Its HD focus and illumination system perform reliably across typical indoor operational conditions where barcode quality and scanning distance vary. For specific durability or environmental specifications beyond standard warehouse use, contact us today so our team can confirm suitability for your facility.

The Linea Pro Rugged combines enterprise-grade durability with enhanced drop protection, hot-swappable battery capability, and sealed construction—features not found in standard barcode attachments. These capabilities reduce equipment replacement costs and downtime while supporting demanding 24/7 warehouse and logistics operations. Contact us today to discuss how the Linea Pro Rugged can improve your mobile scanning efficiency.

The TM-L90II supports label widths from 8mm to 112mm and is compatible with thermal transfer and direct thermal label stock commonly used in warehouse and logistics operations. The printer handles various label materials including paper, synthetic, and semi-gloss stocks, making it versatile for shipping labels, inventory tags, and product labeling applications. We have a full selection of compatible label media available—visit barcodesinc.com to explore options for your specific labeling needs.
