Altronix RBST

Altronix Accessory - Relay Module (6VDC, 12VDC or 24VDC Operation)
$19.27
Temporarily out of stock; available to order
Provides 24 VAC or 28 VAC distributed via sixteen (16) fuse or PTC protected outputs.
The Altronix ALTV2416 Power Supply provides 24 VAC or 28 VAC distributed via sixteen (16) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. It has a supply current of 24 VAC @ 8 amp (200VA) or 28 VAC @ 7 amp (200VA). Main fuse is rated @ 10 amp/250V. It has a power ON/OFF switch. ALTV2416 Power Supply's ease of installation saves time and eliminates costly labor.
Altronix RBST Overview
RBST relay module is designed for continuous duty. This rugged, reliable and dependable relay will handle many switching application.
Protect Your Product
Physical Characteristics
Height:
1"
Width:
2"
Depth:
2.8"
Weight (Approximate):
7.68 oz
Miscellaneous
Additional Information:
    Input Voltage:
    • 6VDC, 12VDC or 24VDC operation
    • Current draw: 30mA
    Contact Rating:
    • 1 amp/120VAC or 2 amp/28VDC DPDT contacts
    Electrical:
    • Operating temperature: -25° C to 55° C ambient
    System AC input VA requirement:
    • 6VDC: 1.8VA
    • 12VDC: 3.6VA
    • 24VDC: 7.2VA
    Environmentally Friendly:
    Yes
    Environmental Certification:
    RoHS
    Warranty
    Limited Warranty:
    Lifetime
    Item Numbers
    GTIN: 0782239930371
    UPC: 782239930371
    EAN: 0782239930371


    The Altronix RBST is also known as ALT-RBST .
