Altronix MAXIMAL1RH

Altronix Accessories - Access Power Controller (8 Fuse Protected Outlets)
$461.90
Temporarily out of stock; available to order
Provides 24 VAC or 28 VAC distributed via sixteen (16) fuse or PTC protected outputs.
The Altronix ALTV2416 Power Supply provides 24 VAC or 28 VAC distributed via sixteen (16) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. It has a supply current of 24 VAC @ 8 amp (200VA) or 28 VAC @ 7 amp (200VA). Main fuse is rated @ 10 amp/250V. It has a power ON/OFF switch. ALTV2416 Power Supply's ease of installation saves time and eliminates costly labor.
Altronix MAXIMAL1RH Overview

Maxim1RH units distribute and switch power to access control systems and accessories. They convert a 115VAC 50/60Hz input into eight (8) independently controlled 12VDC or 24VDC fuse protected outputs. Outputs are activated by an normally open (NO) or normally closed (NC) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button, PIR, etc. Units will route power to a variety of access control hardware devices including: Mag Locks, Electric Strikes, Magnetic Door Holders, etc. Outputs will operate in both Fail-Safe and/or Fail-Secure modes. The FACP Interface enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm disconnect feature is individually selectable for any or all of the outputs.

Protect Your Product
Technical Information
Receptacles:
8
Power Description
Input Voltage:
110 V AC
Output Voltage:
  • 12 V DC
  • 24 V DC
Physical Characteristics
Height:
3.3"
Width:
19.1"
Depth:
8.5"
Miscellaneous
Compatibility:

Access Control Devices:

  • Mag Locks
  • Electric Strikes
  • Magnetic Door Holders
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Country of Origin:
United States
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN: 0782239947379
UPC: 782239947379
EAN: 0782239947379
UNSPSC: 39121004


The Altronix MAXIMAL1RH is also known as ALT-MAXIMAL1RH .
