Altronix HUBWAY82DI

Altronix Accessories - HubWay Video Console/Extender - 8 Input Device - 8 Output Device - 750 ft. Range - 8 x Network (RJ45) - Serial Port - Twisted Pair - Category 5 - Rack-mountable, Wall Mountable
$649.40
Temporarily out of stock; available to order
Provides 24 VAC or 28 VAC distributed via sixteen (16) fuse or PTC protected outputs.
The Altronix ALTV2416 Power Supply provides 24 VAC or 28 VAC distributed via sixteen (16) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. It has a supply current of 24 VAC @ 8 amp (200VA) or 28 VAC @ 7 amp (200VA). Main fuse is rated @ 10 amp/250V. It has a power ON/OFF switch. ALTV2416 Power Supply's ease of installation saves time and eliminates costly labor.
Altronix HUBWAY82DI Overview

Altronix HubWay82Di Passive UTP Transceiver Hub w/Integral Isolated Camera Power transmits UTP video, RS422/RS485 data and power over a single CAT-5 or higher structured cable. Unit provides 8 camera channels in a space saving 1U EIA 19" rack mount chassis which may be rack, wall or shelf mounted. Video transmission range is up to 750 ft. max. per channel. Units are compatible with AC fixed or PTZ cameras when utilizing Altronix HubWayAv Video Balun/Combiners. In addition, the unit features individually selectable 24VAC or 28VAC electronically isolated PTC protected outputs with surge suppression. An optional HubSat4D Passive UTP Transceiver Hub with Integral Isolated Camera Power can be used as an accessory module to transmit video from up to 4 cameras over a single CAT-5 or higher structured cable back to the HubWay8Di. In addition, the HubSat4D provides power to these cameras locally to eliminate the possibility of voltage drop associated with long cable runs.

Protect Your Product
Technical Information
Connectivity Technology:
Wired
Number of Input Devices Supported:
8
Number of Output Devices Supported:
8
Maximum Operating Distance:
750 ft
Interfaces/Ports
Network (RJ-45):
Yes
Serial Port:
Yes
Number of Network (RJ-45) Ports:
8
Media & Performance
Media Type Supported:
Twisted Pair
Twisted Pair Cable Standard:
Category 5
Power Description
Input Voltage:
  • 115 V AC
  • 230 V AC
Physical Characteristics
Transmitter Height:
1.63"
Transmitter Width:
19.13"
Transmitter Depth:
8.50"
Form Factor:
  • Rack-mountable
  • Wall Mountable
Miscellaneous
Package Contents:
  • HubWay Video Console/Extender
  • 2 x Mounting Brackets
  • 6 x Flat Head Screws for Mounting Brackets
  • 4 x Rubber Pads
  • 8 x Video Balun/Combiners
  • Grounded Line Cord
Certifications & Standards:
  • UL 2044
  • CUL
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN: 0782239942947
UPC: 782239942947
EAN: 0782239942947
UNSPSC: 45111815


The Altronix HUBWAY82DI is also known as ALT-HUBWAY82DI .
