Full specifications (PDF)
Protection Type:
- Short Circuit
- Thermal Overload
Altronix ALTV615DC8UL Power Device
Part Number:
ALTV615DC8UL
Model:
ALTV615DC8UL
Altronix ALTV615DC8UL Power Device Model Overview
The Altronix ALTV615DC8UL Power Supply is designed with eight (8) individual class 2-rated, fuse or PTC protected, power limited outputs for powering CCTV Cameras and other video accessories. It has a 6VDC-15VDC adjustable output. ALTV615DC8UL Power Supply has a 4 amp continuous supply current. It has filtered and electronically regulated outputs. Other features include power ON/OFF switch, AC input and DC output LEDs, and spare fuses (fuse protected model only).
Altronix ALTV615DC8UL Power Device Overview
These Altronix DC Wall Mount CCTV Power Supply is designed with eight (8) individually Class 2 Rated fuse or PTC protected power limited outputs for powering CCTV Cameras and other video accessories.
Technical Information
Power Description
Input Voltage Type:
AC
Input Voltage:
110 V AC
Output Voltage:
- 6 V DC
- 15 V DC
Input Current:
900 mA @ 110V
Interfaces/Ports
Plug/Connector:
On/Off Switch
Physical Characteristics
Form Factor:
Wall Mount
Height:
13.5"
Width:
13"
Depth:
3.3"
Weight (Approximate):
9.80 lb
Miscellaneous
Compatibility:
- Heaters
- CCTV Cameras
- Video Accessories
NDAA Compliant:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN:
0782239936236
UPC:
782239936236
EAN:
0782239936236
UNSPSC:
39121004
Get help from a Barcoding Expert!
The Altronix ALTV615DC8UL Power Device is also known as
ALT-ALTV615DC8UL
