Alien ALR-9611-CR RFID Reader

Part Number: ALR-9611-CR
Model: Parts
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Frequency Band Type
UHF
Operating Frequency Range
890 MHz to 930 MHz
Antenna Gain
6 dBi
Impedance
50 Ohm

Product Description:

  915Mz Circular Antenna for use with Alien UHF Readers
Explore all Alien Parts RFID Tags
Add to Quote
Alien ALR-9611-CR RFID Reader
Alien ALR-9611-CR RFID Reader

Alien Parts RFID Tag Model Overview

Products and parts from Alien.
Alien ALR-9611-CR RFID Reader Overview

ALR-9611-CR UHF Antenna uses circular polarization to distribute the UHF energy uniformly in a radially symmetrical pattern, providing the ability to read RFID tas regardless of orientation.

Technical Information
Frequency Band Type:
UHF
Operating Frequency Range:
890 MHz to 930 MHz
Antenna Gain:
6 dBi
Impedance:
50 Ohm
Polarization:
Circular
Interfaces/Ports
Connector Type:
RP-TNC
Physical Characteristics
Height:
11.18"
Width:
7.68"
Depth:
1.70"
Weight (Approximate):
1.50 lb
Miscellaneous
Application/Usage:
Radio Communication
Additional Information:
  • Cable: LMR-195, 50 ohm coaxial
  • Beam-width (3DB): 40 degrees nominal
Item Numbers
UNSPSC: 43221706
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Alien ALR-9611-CR RFID Reader is also known as ALN-ALR-9611-CR or ALR-9611-CR.
