Aleph MY-60 Motion Detector

Aleph MY60 - MY-60 Photoelectric Beam Detector - IrDA - 400 ft. Operating Range - 180 & deg, Viewing Angle - 50 ms to 500 ms Time Delay - Black

Full specifications (PDF)

A high-quality, long-distance dual-beam photoelectric detector
The Aleph MY60 provides the most advanced features in a very attractive, compact weather resistant design. Included in the MY60 series are dual beam - pulsed infrared, sealed optics, variable beam interruption time, indoor/outdoor use, metered voltage outputs and a simple-to-use viewfinder for easy alignment. Wall and/or pole mounting hardware is included. Detection distance of the MY60 is 65 yards outdoor / 130 yards indoor.
Aleph MY-60 Overview

Our most popular Dual Beams, Photo-electric Detectors provide the most advanced features in a very attractive, compact weather resistant design. Included in our "MY" series are Dual Beam - Pulsed Infrared, Sealed Optics, Variable Beam Interruption Time, Indoor/Outdoor Use, Metered Voltage Outputs, and Simple-To-Use Viewfinder for Easy Alignment.

Protect Your Product

Full specifications (PDF)

Technical Information
Wireless Technology:
Infrared
Minimum Motion Sensing Distance:
200 ft
Maximum Motion Sensing Distance:
400 ft
Maximum Viewing Angle:
180°
Maximum Time Delay:
500 ms
Physical Characteristics
Color:
Black
Miscellaneous
Package Contents:
  • MY-60 Photoelectric Beam Detector
  • Wall/Pole Mounting Hardware
Additional Information:
  • Indoor, outdoor use
  • Dial beam - pulsed infrared, sealed optics
  • Variable beam interruption time
  • Alarm Output Form A or Form B / NC/NO (selectable), 24 VDC / 200 mA
  • Alarm Duration 2 sec. ±1 sec
  • Supply Voltage: 11 to 26 VDC
  • Material: Polycarbpnate
Item Numbers
GTIN: 0609613496028, 6938942620038
UPC: 609613496028
EAN: 0609613496028, 6938942620038
UNSPSC: 46171608


The Aleph MY-60 is also known as ALP-MY60 or MY60 .
