Application/Usage:
Optical Network
Adtran 1184002L5 Data Networking
Part Number:
1184002L5
Model:
Parts
Adtran Parts Accessory Model Overview
Products and parts from Adtran.
Adtran 1184002L5 Data Networking Overview
The OPTI-3 Controller Module provides 3 electrical DS3 drops from a single or redundant OC-3 interface when used with an OPTI-3 chassis.
Technical Information
Interfaces/Ports
Total Number of Ports:
2
Connector Type:
- DB-9
- SC
Interfaces/Ports Details:
- 1 x SC Duplex OC-3
- 1 x DB-9 Management
Media & Performance
Media Type Supported:
Optical Fiber
Fiber Mode Supported:
Single-mode
Network Technology:
OC-3
Maximum Distance Supported:
131233.60 ft
Maximum Data Transfer Rate:
155.52
Physical Characteristics
Form Factor:
Hot-pluggable
Height:
5.5"
Width:
1.3"
Depth:
10.3"
Weight (Approximate):
0.87 lb
Miscellaneous
Additional Information:
- External ACO input (RMC only)
- Three audible alarm outputs including Critical, Major, and Minor (RMC only)
- Three visual alarm outputs including Critical, and Minor (RMC only)
- Provide three Clear Channel DS3 Signals (via BNC connectors)
- Two external DS1 BITS clock interfaces
- Three sense points including AUX1, AUX2, and AUX3
Compatibility:
- OPTI-3 Rackmount Chassis
- OPTI-3 Wallmount Chassis
Warranty
Limited Warranty:
5 Year
Item Numbers
UNSPSC:
43222612
