Adesso Nuscan 5200TU – Barcode Scanner – Cordless – 1D, 2D

Part Number: NUSCAN5200TU
Model: Nuscan 5200TU
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$219.40
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Cordless
Form Factor
Handheld
Interface Options
USB
Scanner Capability
1D, 2D

Product Description:

  Barcode Scanner, Adesso 5200TU, Nuscan 5200TU, Antimicrobial and Waterproof 2D Barcode Scanner, Drop Protection, 2D & 1D Scanning Engine, Superior Scanning Performance
Explore all Adesso Nuscan 5200TU Barcode Scanners
Add to Quote
Adesso NUSCAN5200TU Barcode Scanner
Adesso NUSCAN5200TU Barcode Scanner
Adesso NUSCAN5200TU Barcode Scanner
Adesso NUSCAN5200TU Barcode Scanner
Adesso NUSCAN5200TU Barcode Scanner
Adesso NUSCAN5200TU Barcode Scanner
Adesso NUSCAN5200TU Barcode Scanner Adesso NUSCAN5200TU Barcode Scanner Adesso NUSCAN5200TU Barcode Scanner Adesso NUSCAN5200TU Barcode Scanner Adesso NUSCAN5200TU Barcode Scanner Adesso NUSCAN5200TU Barcode Scanner
Full specifications (PDF)

Adesso Nuscan 5200TU Barcode Scanner Model Overview

The ADESSO Nuscan 5200TU is an innovative 2D barcode scanner designed for demanding environments. With its robust, antimicrobial, and waterproof construction, this scanner is perfect for businesses that prioritize hygiene and durability. Capable of reading both 1D and 2D barcode symbologies, including QR codes and Data Matrix, it ensures a flexible scanning experience. With superior performance delivering scanning speeds of up to 24 inches per second and a long scanning range of up to 12 inches, the Nuscan 5200TU is reliable and efficient.


Key Features:
  • Drop Protection: Survives drops from up to 20 feet.
  • Waterproof & Antimicrobial: IP67 rated for water resistance and built with antimicrobial materials.
  • 2D & 1D Scanning Engine: Supports a wide variety of barcode formats.
  • Superior Scanning Performance: 24 IPS motion tolerance for fast, accurate scans.
  • Long Scanning Range: Capable of scanning barcodes up to 12 inches in depth.

Specifications:
  • Imager: 640 x 480 CMOS
  • Light Source: 650 ± 10 nm visible red LED & White LED
  • Depth of Field: 0-12 inches (@20mil EAN-13, PC 100%)
  • Scan Angle: Roll: +50°, Pitch: ±45°, Yaw: +360°
  • Motion Tolerance: 24 inches per second (IPS)
  • Minimum Bar Width: 5 mil (1D), 10 mil (2D)
  • Indicators: Green LED and Programmable Beeper Tone
  • Dimensions: 7 x 3 x 4 inches (175 x 72 x 100 mm)
  • Weight: 0.35 lbs (160 grams, excluding cable)
  • Operating Temperature: -20°C to 50°C
  • Storage Temperature: -40°C to 70°C
  • Humidity: 5% to 95% (non-condensing)
  • Connectivity: USB
Adesso NUSCAN5200TU Barcode Scanner Overview

The Adesso NuScan 5200TU is compatible with a wide range of 1D and 2D barcode symbologies. With CMOS imager the NuScan 5200TU is able to scan major 2D barcodes such as PDF 417, QR Codes, Data Matrix, and micro QR Code. As your daily peripheral companion, your peripheral must be able to provide you with good hygiene and cleanness. Built with waterproof and antimicrobial substances, the NuScan 5200TU can be cleaned periodically. Its 7 meter drop protection also adds to its ruggedness. With all these great features, the NuScan 5200TU is truly your ultimate barcode scanner.

Features:

Antimicrobial
The Nuscan 5200TU is made with antimicrobial material which prevents the growth of harmful bacteria and protects against the buildup germs.

Waterproof
IP67 Rated. Sealed with a silicone plastic material, this scanner is 100% waterproof and can be cleaned with soap and water or other liquids cleaners. Ranked as a IP67 Waterproof Standard, this device can withstand being submerged in water for up to 30 min up to a depth of 3 feet.

Drop Protection
With its rugged design and durable silicone plastic material, the Nuscan 5200TU is less likely to become damaged due to accidental drops from up to 20 feet.

2D & 1D Scanning Engine
Easily and instantly read 2-dimensional barcode symbologies such as the most common PDF 417, QR, and micro QR Code. 1D barcode symbologies are supported as well, making the Nuscan 5200TU truly reliable

Superior Scanning Performance
The 24 inches per second (IPS) motion tolerance and the innovative high pixels CMOS engine offer fast and accurate scanning results.

More from the Manufacturer

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
1D:
  • UPC-A/E
  • EAN13/8
  • Code 128
  • GS1-128
  • Code 39 (Plain&Full ASCII)
  • Code 93
  • Code 11
  • Code 25 (ITF/Industrial/Matrix/IATA Standard)
  • Codabar
  • MSI/MSI Plessey
  • GS1 DataBar
2D:
  • PDF 417
  • Data Matrix
  • QR
  • Micro QR
Image Sensor Type:
CMOS
Scanner Range:
Long Range
Scanning Distance:
12"
Reading Angle (Pitch):
45°
Reading Angle (Roll):
50°
Motion Tolerance:
24 in/s
Drop Specification:

Withstanding 7m freefall drops

Minimum Print Contrast:
30%
Minimum Element Resolution (Code 39):
5 mil
Minimum Element Resolution (DataMatrix):
10 mil
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Form Factor:
Handheld
Color Family:
Dual Color
Product Color:
  • Yellow
  • Black
Height:
4"
Width:
3"
Length:
7"
Weight (Approximate):
5.60 oz
Miscellaneous
Package Contents:
  • NuScan 5200TU- Antimicrobial & Waterproof 2D Barcode Scanner
  • Quick Start User Guide
Ingress Protection (IP) Rating:
IP67
Application/Usage:
  • Industrial
  • Healthcare
  • Logistics
  • Library
  • Retail
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Item Numbers
GTIN: 0783750008594, 0818240992258, 0993247470920
UPC: 783750008594, 818240992258, 993247470920
EAN: 0783750008594, 0818240992258, 0993247470920
UNSPSC: 43211701
