3M Touch Systems 98-0003-3601-0 Touchscreen

Part Number: 98-0003-3601-0
Model: Parts
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
22"
Viewable Screen Size
22"
Screen Mode
WSXGA+
Response Time
8 ms

Product Description:

  3M C2254PW 22" LCD Touchscreen Monitor - 8 ms - 22" Class - CapacitiveMulti-touch Screen - 1680 x 1050 - WSXGA+ - 16.7 Million Colors - 1,000:1 - 300 Nit - DVI - USB - VGA - RoHS - 1 Year
Explore all 3M Touch Systems Parts Accessories
Add to Quote
3M Touch Systems 98-0003-3601-0 Touchscreen
3M Touch Systems 98-0003-3601-0 Touchscreen
3M Touch Systems 98-0003-3601-0 Touchscreen
3M Touch Systems 98-0003-3601-0 Touchscreen 3M Touch Systems 98-0003-3601-0 Touchscreen 3M Touch Systems 98-0003-3601-0 Touchscreen

3M Touch Systems Parts Accessory Model Overview

Products and parts from 3M-MicroTouch.
3M Touch Systems 98-0003-3601-0 Touchscreen Overview

The 22-inch 3M Multi-Touch Display C2254PW combines a 3M Projected Capacitive touchscreen that delivers an ultra-fast, accurate, and precise 10 finger touch response, with a high-definition, wide viewing angle LCD, to create a multi-touch chassis for your next generation interactive application. The rugged all steel frame and a highly-durable glass front surface provide the durability needed for demanding public use environments.

Technical Information
Screen Size Class:
22"
Viewable Screen Size:
22"
Screen Mode:
WSXGA+
Response Time:
8 ms
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Video
Maximum Resolution:
1680 x 1050
Color Supported:
16.7 Million Colors
Contrast Ratio:
1,000:1
Brightness:
300 Nit
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
Capacitive
Multi-touch Screen:
Yes
Interfaces/Ports
DVI:
Yes
USB:
Yes
VGA:
Yes
Power Description
Standby Power Consumption:
80 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Height:
12.9"
Width:
19.7"
Depth:
2"
Weight (Approximate):
33.95 lb
Miscellaneous
Certifications & Standards:
  • CC-B
  • CE
  • TUV
  • CCC
Platform Supported:
PC
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0493212687938, 0551119963835
UPC: 493212687938, 551119963835
EAN: 0493212687938, 0551119963835
UNSPSC: 43211903
Questions? Get help from
a POS Expert!

What is your POS application?

The 3M Touch Systems 98-0003-3601-0 Touchscreen is also known as MCT-98000336010 or 98-0003-3601-0.
