Zebra P4D-0U110000-00 Portable Barcode Printer

The Zebra P4D-0U110000-00 Portable Barcode Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Zebra P4T - 203DPI, 4", THERMAL TRANSFER/DIRECT THERMAL, 8MB/16MB MEMORY, SERIAL, USB, EXTERNAL MEDIA SLOT

Printer Type

Mobile

Interface Options

Serial (RS-232), USB

Print Resolution

203 dpi

Max Print Width

4 inch

Direct Thermal/Thermal Transfer Printer offers reliable performance with outstanding printing quality
203 maximum print resolution (dpi) for better reliance and added usability
The printer is capable of printing sharp and detailed monochrome documents quickly
Delivers high-speed, hassle-free labeling solution for your business needs
Ideal to be used in field service, and in any application that has a need to print on the go
4.12" maximum label width to easily accommodate your needs with added productivity
Supports fanfold media type for maximum feasibility and better accommodation of your requirements
Direct Thermal/Thermal Transfer Printer with mobile application/usage provides dependable printing solution with added productivity
Shoulder Strap feature for maximum efficiency and convenience
Comes with 16 MB standard memory to make you productive with the direct thermal/thermal transfer printer smooth performance

Need a different version? See all Zebra P4T Portable Barcode Printers

Discontinued Need Assistance?

Add to Quote

Zebra P4D-0U110000-00 Portable Barcode Printer

Overview

Full specifications (PDF)

Zebra P4T Portable Barcode Printer Model Overview

Zebra brings you the world's first mobile thermal transfer printer with optional RFID upgradability. With the Zebra P4T, you can print long-life barcode labels and documents up to 4" wide that withstand harsh and outdoor enivronments. With the latest Bluetooth 2.0 or 802.11b/g wireless connectivity, battery monitoring, large LCD, center-loading media and large memory, the P4T boasts an array of features that easily handle your printing needs while being intuitive and user-friendly. Don't let the sleek appearance fool you: the advanced, ergonomic design stands up to the most demanding work environments. The P4T serves many industries, including government, manufacturing, transportation, logistics, mobile workforce and healthcare.

Zebra P4D-0U110000-00 Portable Barcode Printer Overview

Zebra brings you the world's first mobile thermal transfer printer with optional RFID upgradability. With the P4T, you can print long-life bar code labels and documents up to 4" wide that withstand harsh and outdoor enivronments. With the latest Bluetooth 2.0 or 802.11b/g wireless connectivity, battery monitoring, large LCD, center-loading media and large memory, the P4T boasts an array of features that easily handle your printing needs while being intuitive and user-friendly.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Print Color Capability:

Monochrome

Maximum Mono Print Speed:

3 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

Barcode Symbology Supported:

Code 39
Code 93
UCC/EAN 128
Code 128
Codabar
Interleaved 2 of 5
UPC-A
UPC-E
EAN-8
EAN-13
EAN-8 With 2 or 5 Digit Extension
EAN-13 With 2 or 5 Digit Extension
PDF-417
Maxi Code
QR Code
RSS
GS1 DataBar
Aztec Code
Data Matrix

Peel Facility:

Yes

Application/Usage:

Mobile

Features:

Shoulder Strap
LCD Display
RFID Ready

Memory

Standard Memory:

16 MB

Memory Technology:

SRAM

Flash Memory:

8 MB

Interfaces/Ports

Serial Port:

Yes

USB:

Yes

Display & Graphics

Display Screen:

Yes

Display Screen Type:

LCD

Media Types & Handling

Media Type:

Fanfold
Receipt
Tag
Tag Stock
Black Bar
Gap
Continuous Label
Continuous Receipt

Media Sensor:

Adjustable Media Sensor
Reflective Media Sensor

Media Thickness:

8.50 mil

Maximum Roll Diameter:

2.60"

Maximum Label Width:

4.12"

Label Core Size:

1.38"

Fonts & Emulation

Language Emulation:

CPCL
EPL
XML
ZPL
EPL2

Power Description

Power Source:

Battery

Battery Information

Battery Chemistry:

Lithium Ion (Li-Ion)

Battery Included:

Yes

Physical Characteristics

Form Factor:

Portable

Height:

8.6"

Width:

Depth:

Weight (Approximate):

2.90 lb

Miscellaneous

Package Contents:

P4T Mobile Label Printer
Shoulder Strap
Smart Battery
Ribbon Cartridge

Platform Supported:

Certifications & Standards:

FCC Part 15
EN55022 Class B
IEC 60950
NRTL
EMC
LVD
R&TTE

Warranty

Limited Warranty:

1 Year

Item Numbers

UNSPSC: 43212108

Q&A

Questions? Get help from a
Printer Expert!

The Zebra P4D-0U110000-00 Portable Barcode Printer is also known as ZEB-P4D0U11000000 or P4D-0U110000-00.
