Symbol LS4278-SR20007ZZWR Barcode Scanner

Zebra LI4278-SR20007WR Barcode Scanner A newer version of this item is available.
It is replaced by the Zebra LI4278-SR20007WR Barcode Scanner.
Symbol LS 4278 - Scanner only with Bluetooth. Color: black. RoHS Compliant. Cables and accessories must be purchased separately. Options are USB (Part# CBA-U01-S07ZAR), PS/2 (Part# CBA-K01-S07PAR), or RS-232 Serial cables (Part# CBA-R01-S07PAR), Power supply (Part# PWRS-14000-253R) and either Charging/Communications (Part# STB4278-C0007WR) or Charging-only cradles (Part# STB4208-C0007R).
  • Minimizes your manual entry and provides reliable scanning in a durable form factor
  • Increases productivity by giving the opportunity to wander, without the tangle of cables
  • With laser scanning technology you don't have to use any additional lighting as it works effectively in low ambient lighting conditions too
  • Bluetooth technology - Allows compatibility with most of your smart devices
Read More
Discontinued See Replacement
Add to Quote
Symbol LS 4278 Barcode Scanner Model Overview
The Symbol LS 4278 helps users increase productivity and cut costs while providing free movement throughout the workspace. Its unique array of productivity-enhancing features allow novice and advanced users to process items more rapidly and spend less time keying in data. The addition of Bluetooth wireless communications provides workers with the cordless freedom to move to large bulky items for scanning instead of risking injury from lifting heavy objects plus the ability to physically check all sides of a shopping cart for unscanned items. The LS 4278 communicates via Bluetooth to the cradle, which in turn connects to the host computer via a variety of connection interfaces, including USB, keyboard wedge and RS-232.
Symbol LS4278-SR20007ZZWR Barcode Scanner Overview

Symbol's cordless LS4278 provides superior bar code scanning in a durable future-proof device that delivers an outstanding total cost of ownership. Workers can move within a 50 ft/15m radius to scan items and the elimination of hazardous cables creates a safer work environment.

Technical Information
Connectivity Technology:
Wireless
Barcode Symbology Supported:
  • UPC/EAN Supplementals
  • Code 39
  • Code 39 Full ASCII
  • Code 39 TriOptic
  • RSS Variants
  • UCC/EAN 128
  • Code 128
  • Code 128 Full ASCII
  • Code 93
  • Codabar (NW1)
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • MSI
  • Code ll
  • IATA
  • Bookland EAN
  • Code 32
Light Source:
Laser
Maximum Scan Resolution:
5 mil
Depth of Field:
  • 1.5" - 5.5"@5mil - Code 39
  • 0" - 19"@13mil - 100% UPC/EAN
  • 0" - 14"@10mil - Code 39
  • 0" - 29"@20mil - Code 39
Scan Pattern:
2D Raster
Scanning Distance:
50 ft
Network & Communication
Bluetooth:
Yes
Interfaces/Ports
Host Interface:
Multi-interface
Power Description
Input Voltage:
5 V DC
Physical Characteristics
Color:
Black
Height:
7.3"
Width:
2.7"
Depth:
3.9"
Weight (Approximate):
8.40 oz
Miscellaneous
Package Contents:
  • LS4278 Bar Code Reader
  • NiMH Battery
Additional Information:

USB Cable separate

Certifications & Standards:

Electrical Safety:

  • UL1950
  • CSA C22.2 No. 950
  • EN60950/IEC950

Laser Safety:

  • CDRH Class II
  • IEC Class 2

EMI/RFI:

  • FCC Part 15 Class B
  • ICES-003 Class B
  • European Union EMC Directive
  • Australian SMA

Radio:

  • Bluetooth Class 2 Version 1.2
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0710500172656
UPC: 710500172656
EAN: 0710500172656
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Symbol LS4278-SR20007ZZWR Barcode Scanner is also known as SYM-LS4278SR20007ZZR or LS4278SR20007ZZWR.
