Full specifications (PDF)
Connectivity Technology:
Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- UPC/EAN (UPCA/UPCE/UPCE1/EAN-8-EAN-13/JAN-8/JAN13 Plus Supplementals)
- ISBN (Bookland)
- ISSN
- Coupon Code
- Code 39 (Standard, Full ASCII, UCC/EAN-128, ISBT-128 Concatenated)
- Code 93
- Codabar / NW7
- Code 11 (standard, Matrix 2 of 5)
- MSI Plessey
- I2 of 5 (Interleaved 2 of 5 / ITF, Discrete 2 of 5 IATA, Chinese 2 of 5)
- GS1 Databar (Omnidirectional, Truncated, Stacked, Stacked Omnidirectional, Limited, Expanded, Expanded Stacked, Inverse)
- Base 32 (Italian Pharmacode)
2D:
- TLC-39
- Aztec (Standard, Inverse)
- MaxiCode
- DataMatrix/ECC 200 (Standard, Inverse)
- QR Code (Standard, Inverse and Micro)
Postal:
- U.S
- Postnet and Planet
- U.K
- Japan
- Australian
- Netherlands KIX Code
- Royal Mail 4 State Customer
- UPU ICS 4 State Postal
- USPS 4CB
- Canadian Post (Postbar)
PDF417 (and Variants):
- PDF417
- microPDF417
- Composite Codes (CC-A, CC-B, CC-C)CC-B, CC-C)
Light Source:
Laser
Image Sensor Type:
Imager
Depth of Field:
- 0.5" - 6.3"@5mil - Code 39
- 1.3" - 5.4"@6mil - Code 128
- 8"@10mil - Code 128
- 0.6" - 7.2"@7.8mil - 60% UPC
- 1.2" - 14.2"@13mil - 100% UPC
- 1.9" - 3.5"@5mil - PDF
- 1" - 5.9"@6.6mil - PDF
- 8"@10mil - PDF
- 1.1" - 7.2"@10mil - DataMatrix
Scan Pattern:
Omni-directional
