ITW Linx DL1200 Loop Protection Surge Protector

Exceeds TIA/EIA Standards 568 and 758 for category 5e performance

DL1200 Loop Protection ensures the protection of your CAT5 lines from damaging surges and spikes. The device features 12-ports with replaceable 4-port modules and 110 punch-down input to RJ45 output, and is ideal for the protection LAN/Data applications. Solid-state protection provides the fastest response to transient voltages (1-5 nanoseconds) by quickly diverting damaging surges to ground. It also features Signal Perfect Circuitry for auto-resetting surge protection for data networks, telephone and coax lines.

Standard features:
All configurations include 12 Ports, CAT5E, Connectors I/O, Solid State Self-Resetting Technology

Part #	Description	Price
DL1200-T1A	ITW-Linx DL1200 Loop Protection 70V clamping, RJ45, UL listed secondary	Check Availability
DL1200-T1	ITW-Linx DL1200 Loop Protection 70V Clamping, RJ45, UL listed primary	Check Availability
DL1200 235	ITW-Linx DL1200 Loop Protection 235V Clamping, 110/RJ45, UL listed primary & isolated loop	Check Availability
DL1200	ITW-Linx DL1200 Loop Protection 16V Clamping, 110/RJ45, UL listed primary & isolated loop	Check Availability
