APC SURT15KRMXLT-TF5 Accessory

Part Number: SURT15KRMXLT-TF5
Model: Back-UPS Series
Add to My Shopping List Add to Compare
$31,808.46

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Plug/Connector Type
Hard Wire 3-wire
Receptacle Type
Hard Wire 3-wire (2PH + G)NEMA 5-20RNEMA L6-20RNEMA L6-30R
Receptacle Detail
1 x Hard Wire 3-wire (2PH + G)12 x NEMA 5-20R4 x NEMA L6-20R1 x NEMA L6-30R
Number of Battery & Surge Outlets
17

Product Description:

  APC by Schneider Electric Smart-UPS On-Line SURT15KRMXLT-TF5 15 kVA Tower/Rack Mountable UPS - 14U Rack/Tower - 2.50 Hour Recharge - 8 Minute Stand-by - 220 V AC Input - 120 V AC, 208 V AC Output - 1 x Hard Wire 3-wire, 12 x NEMA 5-20R, 4 x NEMA L6-20R, 1 x NEMA L6-30R
Explore all APC Back-UPS Series Accessories
Add to Quote
APC SURT15KRMXLT-TF5 Accessory
APC SURT15KRMXLT-TF5 Accessory
APC SURT15KRMXLT-TF5 Accessory
APC SURT15KRMXLT-TF5 Accessory
APC SURT15KRMXLT-TF5 Accessory
APC SURT15KRMXLT-TF5 Accessory APC SURT15KRMXLT-TF5 Accessory APC SURT15KRMXLT-TF5 Accessory APC SURT15KRMXLT-TF5 Accessory APC SURT15KRMXLT-TF5 Accessory
Full specifications (PDF)

APC Back-UPS Series Accessory Model Overview

An Back-UPS Series instantly switches your computer to emergency battery backup power and allows you to work through brief power outages or to shut down your system in the event of an extended outage. High-performance surge suppression protects your computer from electrical noise and damaging power surges - even lightning.
APC SURT15KRMXLT-TF5 Accessory Overview

The APC Smart-UPS RT is an online UPS with transformer and a power rating of 15kVA and output power capacity of 12000 watts. It includes multiple output connections such as NEMA 5-20R, NEMA L6-20R and NEMA L6-30R. This model is includes a lead-acid battery and is rack-mountable. It features a double conversion online topology, sine wave waveform type, and built-in bypass.

Full specifications (PDF)
Technical Information
Plug/Connector Type:
Hard Wire 3-wire
Receptacle Type:
  • Hard Wire 3-wire (2PH + G)
  • NEMA 5-20R
  • NEMA L6-20R
  • NEMA L6-30R
Receptacle Detail:
  • 1 x Hard Wire 3-wire (2PH + G)
  • 12 x NEMA 5-20R
  • 4 x NEMA L6-20R
  • 1 x NEMA L6-30R
Number of Battery & Surge Outlets:
17
Overload Protection:
Yes
Power Description
Load Capacity (VA):
15 kVA
Input Voltage:
208 V AC
Output Voltage:
  • 120 V AC
  • 208 V AC
Input Frequency:
60 Hz
Output Frequency:
60 Hz
Input Current:
83 A
Waveform Type:
Sine Wave
Management
Network Management:
SNMP Manageable
Bypass Switch:
  • Automatic
  • External (Optional)
  • Internal
  • Manual
  • Static
Emergency Power OFF:
Yes
Interfaces/Ports
Serial Port:
Yes
Network (RJ-45):
Yes
Modular Slots:
SmartSlot
Battery Information
Number of Batteries:
4
Battery Characteristics:
Maintenance-free/Sealed/Spill Proof
Battery Chemistry:
Lead Acid
Backup/Run Time (Full Load):
8 Minute
Typical Battery Recharge Time:
2.50 Hour
Physical Characteristics
Color Family:
Black
Product Color:
Black
Form Factor:
Rack-mountable
Rack Height:
14U
Mounting Location:
Front
Mounting Preference:
Lower
Height:
24.5"
Width:
17"
Depth:
30.4"
Weight (Approximate):
641.35 lb
Miscellaneous
For Country/Region:
United States
Certifications & Standards:
UL 1778
Optimized Energy Efficiency:
Yes
Product Take Back Program:
No
RoHS Exemption Information:
https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SURT15KRMXLT-TF5_ROHS_DECLARATION&p_FileName=SURT15KRMXLT-TF5KIT_ROHS_DECLARATION_US.pdf
REACH Declaration URL:
https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=65035862&lang=en-us
EU RoHS Declaration URL:
https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=65035862&lang=en-us
Environmental Profile Availability:
https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1512017_EN
End of Life Manual Availability:
https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512017_EN
California Proposition 65 Warning:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
REACH free of SVHC:
No
Country of Origin:
Philippines
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
2 Year
Additional Warranty Information:
2 years repair or replace
Item Numbers
GTIN: 0731304634638
UPC: 731304634638
EAN: 0731304634638
UNSPSC: 39121011
