Aiphone VC-K Access Control Equipment

The AIPHONE® VC-MW/B Dual Entrance Adaptor is an essential component for the VC-M system, allowing for seamless integration of two entrance stations. This innovative adaptor facilitates selective communication and door release, ensuring that when one entrance station is called, communication is routed directly to it while the other station remains inactive, indicated by a busy tone. Perfect for various applications, including apartment buildings and office complexes, the VC-MW/B enhances security and convenience in multi-entrance environments. With the potential to expand to 58 stations, the VC-MW/B offers robust performance in sizable systems.

Key Features:

• Dual entrance compatibility for increased flexibility.
• Selective communication from entrance to room station.
• Selective door release for enhanced security.
• Busy signal indicates system use, avoiding confusion.
• Expand to 58 stations when used with VC-M panel and VCH add-on panels.
• All features of the VC-M system are retained.

Specifications:

• Power Source: 12V DC (Use PS-12C for up to 26 stations, PS-12F for systems up to 58 stations).
• Wiring:
  • 4 common wires from VC-K to VC-MW/B.
  • 7 wires from VC-MW/B to each VC-M panel.
• Wiring Distance: 1100' with 22AWG.
• Dimensions: 6-1/4" H x 6" W x 1-3/4" D.
• Mounting: Wall mount, 1-gang box or ring.
